Multiple gingival recessions treated with the modified coronally advanced flap in conjunction with mucoderm®, Straumann® Emdogain® and autologous CTG - Dr. F. Benvenuto
-
01/08 - Pre-operative clinical situation. Multiple adjacent gingival recessions.
Multiple gingival recessions treated with the modified coronally advanced flap in conjunction with mucoderm®, Straumann® Emdogain® and autologous CTG - Dr. F. Benvenuto -
02/08 - Incision of the interested area according to the modified coronally advanced flap technique (Zucchelli & De Sanctis J Periodontol. 2000).
Multiple gingival recessions treated with the modified coronally advanced flap in conjunction with mucoderm®, Straumann® Emdogain® and autologous CTG - Dr. F. Benvenuto -
03/08 - mucoderm® inserted to treat the recession around the canine. Molar and pre-molar are treated with autologous tissue (CTG). Root surfaces were pre-treated with Straumann® PrefGel® and Straumann® Emdogain®. The harvesting site is protected with a collagen fleece.
Multiple gingival recessions treated with the modified coronally advanced flap in conjunction with mucoderm®, Straumann® Emdogain® and autologous CTG - Dr. F. Benvenuto -
04/08 - Sutures are applied. The flap is repositioned coronally and the porcine matrix is carefully covered under the flap.
Multiple gingival recessions treated with the modified coronally advanced flap in conjunction with mucoderm®, Straumann® Emdogain® and autologous CTG - Dr. F. Benvenuto -
05/08 - Clinical situation 14 days post-op. Sutures are removed.
Multiple gingival recessions treated with the modified coronally advanced flap in conjunction with mucoderm®, Straumann® Emdogain® and autologous CTG - Dr. F. Benvenuto -
06/08 - Clinical situation 14 days post-op. Sutures are removed.
Multiple gingival recessions treated with the modified coronally advanced flap in conjunction with mucoderm®, Straumann® Emdogain® and autologous CTG - Dr. F. Benvenuto -
07/08 - 2 months post-op. Excellent healing of the region treated with mucoderm®.
Multiple gingival recessions treated with the modified coronally advanced flap in conjunction with mucoderm®, Straumann® Emdogain® and autologous CTG - Dr. F. Benvenuto -
08/08 - Follow-up at 6 months. Tissue around the canine is mature and the recession treated with mucoderm® is succesfully covered.
Multiple gingival recessions treated with the modified coronally advanced flap in conjunction with mucoderm®, Straumann® Emdogain® and autologous CTG - Dr. F. Benvenuto
